How to Use CZUR WritePad?

How to Use CZUR WritePad?

Introduction

As an innovative company in smart office equipment, CZUR is dedicated to providing efficient and intuitive intelligent solutions. In mid-2024, we launched the StarryHub Q1 Pro, followed by the rollout of WritePad’s features at the end of the year. Written for StarryHub, WritePad is a smart handwriting pad with wireless connectivity, seamless screen synchronization, and versatile functions such as note-taking, comments, and mouse mode. It enhances interactivity and efficiency across various scenarios, including hybrid meetings, virtual conferences, video meetings, and educational settings, making work and learning more effective.

Table of Content

1. What is WritePad?
2. WritePad Design and Features

3. How to Use CZUR WritePad?

3.1 How to Pair

3.2 How to Use?

4. Tips for WritePad Maintenance
5. Write Specification

1. What is WritePad?

WritePad is a dedicated smart handwriting pad for CZUR StarryHub, featuring high-precision electromagnetic induction technology for a smooth and natural writing experience. Designed for a wide range of applications—including education, business, design, drawing, and annotation—WritePad serves as an intelligent input device that wirelessly connects to StarryHub. It enables seamless note-taking, comments, and even screen control during collaborative meetings, presentations, and remote conferences, making every session more efficient and intuitive.

Figure1-WritePad

Figure1-WritePad

2. WritePad Design and Features

WritePad features a sleek Iceberg Gray color scheme and a durable aerospace-grade magnesium-aluminum alloy body, combining minimalist aesthetics with a professional business feel. Its main components include:

  • WritePen: Nestled in the pen slot, it serves as both a writing and control tool, with a tail end that functions as an eraser.

  • Power Switch: Located on the back, press and hold for 2 seconds to power the device on or off.

  • Type-C Charging Port: Positioned at the bottom, it enables fast charging, with a 5V power source recommended for optimal performance.

  • Function Buttons: The front features a Note button for note-taking and a Comment button for annotations, each activating a dedicated mode.

    Figure2-WritePad Diagram

Figure2-WritePad Diagram

Beyond its writing capabilities, WritePad seamlessly syncs with StarryHub’s screen content, enabling remote operation and even doubling as a wireless touchpad for enhanced versatility.

3. How to Use CZUR WritePad?

3.1 How to Pair?

To make the WritePad work properly, it needs to be paired with the StarryHub. The steps are as follows:

  1. Press and hold both the Note and Comment buttons for 3 seconds to enter pairing mode on the WritePad.

  2. Go to the StarryHub main interface and open the WritePad.

  3. Click "Go to Settings" in the top right corner, then select "Add WritePad."

  4. Choose the corresponding WritePad device, and the pairing will complete automatically within 10 seconds.

Note: If another WritePad is already paired with the StarryHub, you may need to unbind it first before pairing a new device.

Figure3-writepad pairing

Figure3-writepad pairing

3.2 How to Use?

Once pairing is complete, you can begin using WritePad. It features three main modes, each offering different functions. Before you start, let's go over its wake-up and sleep modes, as well as some important tips.

When you lift the pen from the pen slot, WritePad will automatically enter wake-up mode. You can also briefly press the power button or use the note and comment features to wake it up. When you return the pen to its holder, the device will enter deep sleep mode. With a standby time of approximately 90 days, WritePad minimizes the need for frequent charging and maintenance.

WritePad runs on the Android operating system. It is not a standalone device and must be used in conjunction with StarryHub.

In addition, WritePad supports wireless connections, multi-screen synchronization, OTA (online upgrades), note-taking, and annotation features, and can also function as a mouse or touchpad.

Note Mode

  • Press the Note button to enter the Note mode, and a whiteboard writing interface will appear on the screen.

  • StarryHub will automatically open the Note app, and you can write directly on the WritePad. The content will be displayed on the StarryHub screen without any delay. It also supports repeated edits and color switching. You can save valuable content and find the file on the WritePad within the StarryHub interface. You can also share it on your phone.

  • To modify the content, simply use the back end of the WritePen to gently erase it.

  • To exit the Note mode, click "Quit."

Figure4-note mode

Figure4-note mode

Comment Mode

  • Press the Comment button, and the WritePad will capture the current StarryHub screen.

  • You can directly make annotations on the WritePad, and all the markings will sync to the StarryHub.

  • After finishing the annotations, click "Quit" to exit and return to the StarryHub home page.

Mouse Mode

  • Tap the WritePen to enter Mouse mode.

  • The StarryHub screen will be mirrored on the WritePad, allowing you to control it like a wireless touchpad.

Note: Some StarryHub models may not support this feature. For details, please refer to the CZUR official website.

Figure5-mouse mode

Figure5-mouse mode

4. Tips for WritePad Maintenance

To ensure your WritePad remains in optimal condition, please follow these maintenance tips:

  • Charge the device using a 5V power source to prevent potential damage from voltage fluctuations.

  • Regularly replace the pen tip. If you notice a decrease in writing quality, use the spare pen tip provided in the package.

  • Keep the device away from water and cleaning agents. For cleaning, gently wipe it with a dry, soft cloth.

  • Store WritePad in a cool, dry, and well-ventilated place. Avoid exposing it to high temperatures or humidity to extend its lifespan.

  • Do not attempt to disassemble or repair the device. If you experience any issues, please contact CZUR customer support for assistance.

5. WritePad Specification

Specification

Details

Screen Type

RLCD (Reflective LCD)

Resolution

1280 × 800 (16:10)

Size

10.5 inch

Screen Color

Black & White

Bluetooth

5.2

Bluetooth Range

≈10m

Writing Time

≈20 hours

Standby Time

≈2000 hours

Wake-up Method

Picking up the pen or pressing any key

CPU

1.5GHz

DDR

4G

EMMC

8G

Operating System

WritePadOS (Based on Android)

Battery Capacity

10,800mAh

Charging Port

Type-C

Charging Voltage

5V

Charging Current

≤3A

Charging Time

<6 hours

Auto Power-off

≤1% battery level

Pen Sensing Height

±82mm

Pen Size

157.3mm

Pen Pressure Levels

4096

Writing Accuracy

±0.3mm (center), ±0.5mm (edge)

Writing Latency

<20ms

Eraser on Pen

Supported


Conclusion

WritePad enhances the StarryHub experience, making it an ideal tool for users who need to take notes, annotate content, and remotely control their devices. As a powerful collaboration tool, it streamlines interaction in various scenarios, including team meetings, virtual conferences, and video calls.

For a more detailed walkthrough, check out our YouTube tutorial:

How to get started with CUZR WritePad - Tutorial

We hope this guide helps you get up to speed with WritePad quickly and elevates your StarryHub experience with TouchBoard! Check this guide to use CZUR TouchBoard.
